Technical Video Production
Technical Video Production for Smart Industry
From photorealistic exploded-view renders to BOM-ready drawings and calibration walkthroughs, our video team turns complex mechanical assemblies into crystal-clear stories.
Each clip is engineered in tandem with our 3-D simulation pipeline, giving your technicians, clients, and stakeholders the exact visuals they need to assemble, commission, or market your system—fast.
From photorealistic exploded-view renders to BOM-ready drawings and calibration walkthroughs, our video team turns complex mechanical assemblies into crystal-clear stories.
Each clip is engineered in tandem with our 3-D simulation pipeline, giving your technicians, clients, and stakeholders the exact visuals they need to assemble, commission, or market your system—fast.
In this series, we demonstrate step-by-step how to commission a laser-based communication system—from the first connection to a fully operational link.
Follow along to see the entire startup workflow brought to life, and discover best practices that turn cutting-edge technology into reliable performance.
Follow along to see the entire startup workflow brought to life, and discover best practices that turn cutting-edge technology into reliable performance.
If a building becomes architecture, then it is art
Technical Drawings
• Full-detail drawings for assembly, service & compliance
• Exploded views with call-outs and BOM indexing
• ISO, ANSI or custom title-block formats
• Revision tracking for faster engineering change orders
• Exploded views with call-outs and BOM indexing
• ISO, ANSI or custom title-block formats
• Revision tracking for faster engineering change orders
Sprocket-Roller Shaft • Exploded & Section Views
Multi-sheet technical drawing combining orthographic, section A-A and exploded perspective of a sprocket-roller shaft. A fully-populated BOM (items 1-6) details shaft, double-sprocket, idler wheel and bearing sets. Ideal for maintenance manuals and sourcing packages where dimensional accuracy and part counts are critical.
Roller Conveyor – Side & End Elevations
Detailed fabrication print of a motor-driven roller conveyor with integrated pneumatic pusher. Call-outs (items 9-37) highlight legs, cross-bracing, motor mount and upper platen. Dimensions and hole patterns allow suppliers to quote and manufacture without additional 3-D data.
Pneumatic Cylinder Mount • BOM Drawing
Exploded drawing of a front-flange pneumatic cylinder mount. Item bubbles reference the nine-line parts table (rod clevis, spherical rod end, locator bush, etc.). Perfect for training documents: assemblers see sequence while buyers get part numbers in one view.
Stabiliser Frame • Exploded 3-D View
Colour-coded exploded view of a mobile stabiliser frame: base beam, upright posts, locking clamps and caster wheels are separated for clarity. Use as a step-by-step visual in build guides or interactive animation.
Palletising Gantry Frame (3-×-2 m)
Welded steel support gantry showing linear rail carriages, drive shafts and motor brackets. Designed for an XYZ vacuum pick unit above a pallet stacker. Renders like this help stakeholders validate envelope fit before steel is cut.
Automated Board-Handling Cell
Complete digital twin of a board-inspection and stacking line: twin conveyors, scanner bridge, overhead XYZ gantry and operator platform with stairs. Use the assembly to simulate cycle times, PLC logic and safety envelopes—long before commissioning day.
Three Good Reasons
Three Ways Pro-Level Technical Media Pays Off
From exploded views to step-by-step tutorials, our videos turn engineering complexity into crystal-clear action.
From exploded views to step-by-step tutorials, our videos turn engineering complexity into crystal-clear action.
- Master Assembly at First TryExploded-view videos and annotated drawings cut operator mistakes to near-zero.
- Commission Hardware—VirtuallyCalibration & PLC walk-through clips let your team debug systems before the machine ships.
- Explain the Complex, InstantlyHigh-definition 3-D animations win over investors, clients and maintenance crews alike.
Why Engineers Pick CIDTECH
From exploded-view renders to step-by-step calibration videos, every asset is built to make complex hardware simple.
Production-Ready Accuracy
CAD models are dimensionally exact, so what you see in the video fits first-time on the shop floor.
Faster Commissioning
Interactive clips let PLC & maintenance teams rehearse procedures before the machine even ships.
Presents
Exploded views, call-outs, and part IDs turn dense drawings into training materials that people can watch.
Support
Our managers are always ready to answer your questions. You can call us during the weekends and at night.
Collaborative Reviews
Cloud share-links and frame-accurate comments keep engineers, suppliers and stakeholders aligned.
Quicker Buy-In
High-definition animations sell your concept to investors, end-users and safety auditors alike.
»
We’re not just business — we are creators. We are CIDTECH
We simulate the future. We optimise the present. We design for impact.
Your ideas deserve more than slides – they deserve a simulation.
Let’s Build the Future Together
Whether you're launching a new idea or optimizing an existing system, let's bring it to life together. Reach out and we'll simulate your success.
